[One-button measuring instrument] "Detection" master the core of the factory measuring instrument

One-button measuring instrument is a kind of instrument that can measure the plane size of the workpiece quickly and in batches. Its core advantage is to measure large quantities of small precision parts. So how did the one-button measuring instrument come into being? The one-button measuring instrument can be said to be a new measuring instrument derived from the quadratic measuring instrument.

The initial use of industrial projectors allows for early industrial dimensional measurements. With the development of industry, the factory product measurement is not satisfied with the existing measurement accuracy and efficiency, so the image measuring instrument is developed. Image measuring instrument is divided into manual image measuring instrument, semi-automatic image measuring instrument and automatic image measuring instrument. The production of image measuring instrument lasted for a long time, but in the process of using image measuring instrument, new measurement requirements have been produced.

Although the measurement accuracy and speed of the image measuring instrument have been greatly improved, the measurement principle is still based on the grating ruler measurement, and the product size measurement needs to be carried out one by one. A small amount of product measurement is fine, a large number of products or multi-size product measurement, the need for full-size, full-batch testing, it will cost a lot of time and money. This requires the investment of multiple image measuring instruments and professional measuring personnel. More importantly, although so much is invested, the measurement efficiency can not be improved, and a lot of time is spent on measurement.

One-click image measuring instrument is a new image measurement technology, which transmits the product contour image to millions of pixels or even 29 million high-resolution CCD cameras for digital processing through high-precision dual-telecenter lenses, and then carries out precise measurement, data judgment and output by HW-CCD high-precision software with powerful computing power. The 100 dimensions can be tested in just one second, and the efficiency is 10 times that of the traditional imaging instrument, which can effectively save labor costs and improve test efficiency.

Image measuring instrument is widely used in machinery, electronics, aerospace, mold, spring, gear, terminal terminals, circuit board contacts, hardware and plastic, magnetic materials, electronic circuits, components, watches, hardware stamping industry, ore industry, mobile phone accessories, home appliances, connectors, mechanical accessories, precision clamp, plastic, hardware, computer around the industry measurement.

Why should products be measured one by one? Why can't multiple products be measured together? How to measure multiple dimensions of a product at the same time? How to ensure accuracy while also ensuring measurement efficiency? How to make the measurement more simple and easy to use? It is based on such measurement difficulties that one-button measuring instrument comes into being.

The one-button measuring instrument has really solved these difficulties, and has made a qualitative leap in all aspects. 100 workpiece dimensions can be measured in just 5 seconds. The one-button measuring instrument changes the original measuring method of the grating ruler, and adopts the large-field telocentric imaging + high pixel camera + sub-pixel edge out + least square regression + high algorithm measuring software, which breaks the original measuring concept and barrier.
